Smart Group Meal Machine
LSF860QR
Qualcomm Snapdragon octa-core processor, low power consumption, high performance
Compatible with face recognition, card swiping, and QR code scanning
High-definition color dual screens for easy operation
Supports Ethernet, Wi-Fi, and full-network 4G
Oil-resistant, long-life pull-out mechanical keyboard
Infrared dual-camera
Capacitive touch screen, multi-point touch G+G
Passed 3C, SRRC, CTA certification
Product Advantages
Technical Parameters
| Product Weight | About 1050g (whole machine) About 1500g (with bracket) |
| Dimensions (L × W × H) | 290mm×260mm×105mm |
| Power Input Voltage, Current, Interface | 12V~15V, Maximum 3A, 3.5mm DC socket with lock |
| Rated Power | 24W, Maximum not exceeding 36W |
| Working Environment | Maximum Temperature: -10°C to +45°C, Humidity: 10% to 90%Recommended Temperature: 0°C to +40°C, Humidity: 10% to 80% |
| Dual-screen Display | Operation Screen: 5-inch IPS LCD (480×854)Customer Display Screen: 8-inch IPS LCD (1280×800) |
| Touch Screen | 8-inch capacitive touch screen, G+G |
| CPU and Main Frequency | 8-core 1.8GHz A53, Qualcomm Snapdragon 450 processor |
| Memory | 2G LPDDR3 RAM |
| FLASH | 16GB eMMC |
| Operating System | Android 7.1.2 |
| Built-in Speaker | 4 ohms, 2W (2 pieces) |
| RTC Clock Battery | Yes, button battery life > 2 years |
| Network Interface | Ethernet Port: 10/100Mbps Base-T Auto-adaptive, RJ45 |
| WIFI | 2.4/5G, 802.11a/b/g/n/ac |
| Bluetooth | BT4.2(BR/EDR+BLE) |
| Cellular Network | LTE-FDD: B1/B3LTE-TDD: B39/B40/B41 |
| Camera Module | Dual-camera: Visible light 2 million pixels, 1/2.7"; Infrared 1.3 million pixels, 1/3". With liveness detection functionField of View: 86°Face Recognition Distance: 30-100cmFace Recognition Speed: Fastest 0.2 seconds |
| Non-contact Card Reading | Reading Distance within 4cm, Read/Write Time <0.5 seconds, Communication Frequency 13.56MHz, Communication Protocol ISO/IEC 14443A/B, ISO15693. |
| USB Interface | 2xUSB 2.0, type-A interface |
| Keyboard | Detachable 20-key mechanical keyboard |
| Appearance Color | Black, Green, Material: Glass, PC+ABS plastic |
| Installation Method | Tabletop installation, wall-mounted installation |
