LSD3110X
LSD3110X
Supports RS485/RS232 interface
Compatible with 4G/3G/2.5G
Integrated terminal data transmission
Power consumption far below industry peers
Multi-data center synchronous transmission
Officially promoted product of Alibaba Cloud Hardware Mall and NetEase Cloud Hardware Mall
Supports LTE-TDD, LTE-FDD, GSM
Industrial-grade processor Cortex-A5@500MHz, 1MB SRAM, 1MB Flash
Supports external 16MB Flash storage space
Product Advantages
Technical Parameters
| Name | Data Acquisition Terminal LSD3110X |
| Power | DC9~18V, or DC18~36V or DC9~30V, isolation protection against reverse connection |
| Interface Protection | All interfaces are isolated, ESD protection |
| Working Environment | -30℃~70℃ |
| Protection Level | Level 3 EMC per IEC61000 testing |
| Data Storage | 16MB data storage space, data retention for 10 years |
| Offline Data Transmission | Data preservation and retransmission during offline |
| Supported Protocols | Supports standard ModbusRTU, read and write operations |
| DI Input Support | Supports photoelectric switch, Hall switch, factory piece counting |
| Network Platform | Alibaba Cloud IoT Platform, LeSun IoT Platform |
| Network Protocols | MQTT, HTTP, TCP, UDP, NTP, etc. |
| Custom Development | Protocol customization, support for AliOS Things secondary development |
| Remote Maintenance | OTA remote upgrade |
