LSP982
Palm Vein Recognition Terminal
LESHUN LSP982
Professional palm vein recognition device — New Benchmark in Biometrics
Biometric Technology
Dual-mode verification of
palm print and palm vein
graphic information
Unique Security
Dual-mode palm print & vein recognition: easily distinguish twins; unforgeable & unreplicable
Privacy Protection
Hand gesture activates recognition automatically; minimizes privacy leakage risks
Fast & Convenient
Millisecond-level recognition speed; card & cash-free, height-unrestricted
Contactless & Hygienic
Contactless recognition; lowers cross-infection risks
Multi-Form Installation | Dual Application Scenarios
Access Identity Verification Scenario
Self-service Payment Scenario
Compatible with various brackets for diverse mounting scenarios，auto-adaptive for portrait & landscape mode applications
Wall mount (portrait)
Turnstile integration
Desktop stand mount
Floor stand mount
Embedded in self-service kiosks
Wall mount (landscape)
Wall mount (portrait)
Turnstile integration
Desktop stand mount
Floor stand mount
Embedded in self-service kiosks
Wall mount (landscape)
Slim, Light & Durable
265 mm
Device Length
126 mm
Device Width
32 mm
Device Height
IP65 Protection Rating
Meets the requirements for outdoor & semi-outdoor use
Powerful Performance, High Speedn
High-performance & Low-power Processor
RK3568 Quad-core
CPU
2.0GHz
Max Clock Speed
A55
ARM
2GB RAM + 32GB ROM
Memory & Storage
Ethernet + dual-band WiFi
Ethernet
Stable transmission,high speed & enhanced security
Dual-band WiFi
Low interference, faster transmission, smoother operation
LESHUN LSP982 Specification Sheet
LSP982
OS
Android 13
CPU
4-core 2.0GHz Cortex-A55 CPU, RK3568 Platform
Memory
2GB RAM + 32GB ROM
Display
8-inch, 250 cd/m² Brightness, 800×1280 @ 60fps, Multi-touch capacitive touch display
Bluetooth
BT4.2(BR/EDR+BLE)
Palm Scan (QR Compatible)
Palm recognition distance：6~15cm
Scanner Module
Recognition distance: 30~150mm; Supports 1D & 2D barcodes
NFC
Card reading distance: >1cm; Supports Mifare S50/70, UltraLight, PlusCPU, CPU Cards, etc.
Wi-Fi
2.4G/5GDual-band, 802.11a/b/g/n/ac
Ethernet
10/100 Mbps base-T auto-negotiation; RJ45 port
Interface
1×USB2.0, Type-A Port
1×RJ45 Port
1×Relay Port: White/Yellow/Purple Wire Group
1×RS485: Black/White/Blue/White/Red/White Wire Group
1×Power Port
1×RJ45 Port
1×Relay Port: White/Yellow/Purple Wire Group
1×RS485: Black/White/Blue/White/Red/White Wire Group
1×Power Port
Power
12VDC/3A
Rated Power
15W, Max 30W
Operating Environment
Max Temp: -10°C～+50°C
Humidity: 10%～85%
Recommended Temp: -10°C～+40°C
Recommended Humidity: 10%～80%
Humidity: 10%～85%
Recommended Temp: -10°C～+40°C
Recommended Humidity: 10%～80%
Size & Weight
265mm*126.6mm*25.5mm 0.776kg
Mounting Method
Wall-mounted installation (included bracket) Column-mounted installation (optional desktop bracket)
Audio
Speaker qty: 1; Max. 2W/8Ω output per channel
