LSP980
Palm Vein Recognition Terminal
LESHUN LSP980
Professional palm vein recognition device — New Benchmark in Biometrics
Biometric Technology
Dual-mode verification of
palm print and palm vein
graphic information
Unique Security
Dual-mode palm print & vein recognition: easily distinguish twins; unforgeable & unreplicable
Privacy Protection
Hand gesture activates recognition automatically; minimizes privacy leakage risks
Fast & Convenient
Millisecond-level recognition speed; card & cash-free, height-unrestricted
Contactless & Hygienic
Contactless recognition; lowers cross-infection risks
Tri-mode All-in-One, Payment at Will
Palm Vein Recognition
Dual-mode palm vein & print recognition
Card Recognition
Encrypted IC card/NFC recognition
QR Code Recognition
QR code & Barcode recognition
Dual-touch IPS HD Interactive Screen
5'
Customer Display
10'
Operation Screen
Ideal for food ordering, canteen catering & retail scenarios
5'
Touchable customer display
10'
Touchable operation screen
Horizontal Design, Installation-Free
Network-connected, ready for use upon power-on
290 mm
Length
260 mm
Width
105 mm
Height
1920*1080 FHD
customer display
800*1280 FHD
operation screen
Powerful Performance, High Speed
High-performance & Low-power Processor
Qualcomm Octa-core
CPU
1.8GHz
Max Clock Speed
A53
ARM
2GB RAM + 16GB ROM
Memory & Storage
Smart Canteen
Adapted for campus, government and enterprise canteens. Complete payments quickly via palm vein recognition without a mobile phone.
Member Store
Adapted for membership-based scenarios like gyms, stadiums and bars.
Retail Consumption
Suitable for open supermarket & retail payment scenarios.
Tri-network Supported, Worry-free Payment
Ethernet
Stable transmission,high speed & enhanced security
Dual-band WiFi
Low interference, faster transmission, smoother operation
4G Full Netcom
Maintains connection anywhere, even in poor network conditions
LESHUN LSP980 Specification Sheet
LSP980
OS
Android 7.1.2
CPU
Octa-core 1.8GHz A53,
Qualcomm Snapdragon 450 Processor
Qualcomm Snapdragon 450 Processor
Memory
2GB RAM + 16GB ROM
Dual-screen display
Operation Screen: 10',
Resolution: 1280*800;
Customer display: 5',
Resolution: 480*854;
Multi-touch screen
Resolution: 1280*800;
Customer display: 5',
Resolution: 480*854;
Multi-touch screen
Bluetooth
BT4.2(BR/EDR+BLE)
Wi-Fi
2.4G/5G Dual-band, 802.11a/b/g/n/ac
Cellular Network
LTE-FDD：B1/B3/B5/B8
LTE-TDD：B38/B39/B40/B41
LTE-TDD：B38/B39/B40/B41
Ethernet
10/100 Mbps base-T auto-negotiation; RJ45 port
Scanner Module
Recognition distance: 30~150mm; Supports 1D & 2D barcodes
Interface
2*USB2.0，type-A ports
1*RJ45 ports
1*RJ12 ports
1*SIM card ports
1*power ports
1*RJ45 ports
1*RJ12 ports
1*SIM card ports
1*power ports
Palm Vein Module
Palm recognition distance：5~12cm
NFC
Card reading distance: 3~5cm; Supports Mifare S50/70,
UltraLight, PlusCPU, CPU Cards, etc.
Power
12VDC/3A
Rated Power
18W, Max 36W
Audio
Speaker qty: 1; Rated Power: 2W@5V/4R/1KHz
Size & Weight
290mm*260mm*105mm 1.8kg
Operating Environment
Max Temp: -10°C～+50°C
Humidity: 10%～90%
Recommended Temp: -10°C～+40°C
Recommended Humidity: 10%～80%
Humidity: 10%～90%
Recommended Temp: -10°C～+40°C
Recommended Humidity: 10%～80%
